Description
- Centralized Management: Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers.
- Free Cloud Access: Manage and monitor with the Omada app or Web UI from anywhere, anytime.
- On-Premises Management: Locally monitor and manage devices with the ultimate security and stability.
- Industry-Leading Hardware Design: A powerful chipset, durable metal casing, USB 2.0 port for auto backup, and two Fast Ethernet ports.
- Flexible Power Supply: 802.3af/at PoE or Micro USB (DC 5V/Minimum 1A) for flexible installation.
- Easy and Intelligent Network Monitoring: The easy-to-use dashboard makes it simple to see the real-time network status and traffic distribution.
- Real-Time Network Topology: Helps IT admins quickly see and troubleshoot connections at a glance.
- Easier Network Maintenance: WiFi heatmap simulator, visualizable network report, and batch & multi-site management benefit network maintenance.
| Specifications | ||
| HARDWARE FEATURES | Interface | • 2× 10/100 Mbps Ethernet Port • 1× USB 2.0 Port • 1× Micro USB Port |
| Power Supply | 802.3af/at PoE or Micro USB（DC 5V/Minimum 1A） | |
| Dimensions | 3.9×3.9×1.0in. (100×98×25mm) | |
| MANAGEMENT | Omada App | Yes |
| Centralized Management | • Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers • Up to 1,000 ClientsNote: Please refer to www.tp-link.com/en/business-networking/all-omada/ to find all the device models supported by OC200 |
|
| Cloud Access | Yes | |
| L3 Management | Yes | |
| Multi-site Management | Yes | |
| Management Features | • Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration |
|
| OTHERS | Certification | CE, FCC, RoHS |
| Package Contents | Omada Cloud Controller OC200 Quick Installation Guide Ethernet Cable |
|
| System Requirements | Microsoft® Windows®10, 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
