Features
- Hot-pluggable SFP+ transceiver
- SFP+ MSA compliant
- Supported throughput up to 10.5 Gbps
- Multi Mode fiber for distances up to 550 m (1,804 feet)
- 850 nm wavelength
- Duplex LC connector
- Digital Diagnostics Monitoring (DDM) support
- Operating temperature: 0 to 70 °C (32 to 158 °F)
- Single 3.3 V power supply
| Specifications | |
| Standards | IEEE 802.3ae |
| 10GBASE-SR | |
| Device Interface | SFP+ MSA Compliant |
| LC duplex connector | |
| Data Transfer Rate | 8.5-10.5 Gbps |
| Wavelength | 850 nm |
| Optical Output Power | -1 ~ -7.5 dBm |
| Distance | 550 m (OM4) |
| 300 m (OM3) | |
| 82 m (OM2) | |
| 33 m (OM1) | |
| Special Features | Hot pluggable |
| Metal enclosure | |
| DDM support | |
| Sensitivity | -14 dBm |
| Power | Consumption: 439 mW |
| Operating Temperature | 0 – 70 °C (32 – 158 °F) |
| Operating Humidity | Max. 95% non-condensing |
| Dimensions | 14.8 x 56.5 x 11.85 mm (0.6 x 2.2 x 0.5 in.) |
| Weight | 22 g (0.7 oz.) |
| Certifications | CE |
| FCC | |
