Features
• 24 x Gigabit ports
• 2 x 10G SFP+ slots
• 88Gbps switching capacity
• 1U rack mountable (brackets included)
• Fanless Design
| Specifications | |
| Standards | IEEE 802.3 |
| IEEE 802.3u | |
| IEEE 802.3ab | |
| IEEE 802.3x | |
| IEEE 802.1p | |
| IEEE 802.3ae | |
| IEEE 802.3az | |
| Device Interface | 24 x Gigabit ports |
| 2 x 10G SFP+ slots | |
| LED indicators | |
| Data Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) |
| Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) | |
| Gigabit Ethernet: 2000Mbps (full duplex) | |
| 10 Gigabit Ethernet: 20Gbps (full duplex) | |
| Performance | Switching Capacity: 88Gbps |
| RAM Buffer: 1.5MB | |
| MAC Address Table: 16K entries | |
| Forwarding Rate: 65.5Mpps (64-byte packet size) | |
| Jumbo Frames: 10KB | |
| Power | Input: 100 – 240V AC, 50/60Hz, internal power supply |
| Max. Consumption: 18.9W | |
| Fan/Acoustics | Fanless design |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 440 x 130 x 44mm (17.32 x 5.11 x 1.73 in.) |
| Weight | 1.935kg (4.27 lbs.) |
