Features
• 24 x Gigabit RJ-45 ports
• Sturdy metal switch
• Built-in power supply
• 48Gbps forwarding capacity
• Fanless design
• 1U 19” rackmount brackets included
| Specifications | |
| Standards | IEEE 802.3 |
| IEEE 802.3u | |
| IEEE 802.3x | |
| IEEE 802.3ab | |
| Device Interface | 24x Gigabit ports |
| LED indicators | |
| Data Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) |
| Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) | |
| Gigabit: 2000Mbps (full duplex) | |
| Performance | Switching Capacity: 48Gbps |
| RAM Buffer: 512KB | |
| MAC Address Table: 8K entries | |
| Forwarding Rate: 35.71Mpps (64-byte packet size) | |
| Jumbo Frames: 9KB | |
| Special Features | Rack Mountable |
| Power | Internal power supply: 100 – 240V AC, 50/60 Hz, 1A |
| Max. Consumption: 14.24W | |
| Fan/Acoustics | Fanless design |
| MTBF | 364,460 hours |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions (L x W x H) | 440 x 130 x 44mm (17.32 x 5.12 x 1.73 in.) |
| Weight | 1.73kg (3.81 lbs.) |
| Certifications | FCC |
| CE | |
| ETL | |
