Features
• 5 x 10G RJ-45 ports
• Supports IEEE 802.3bz 2.5G/5G-BASE-T over cat5e cabling (or better)
• Supports IEEE 802.3an 10G-BASE-T over cat6a cabling (or better)
• 100Gbps switching capacity
• Fanless design for silent operation
| Specifications | |
| Standards | IEEE 802.3u |
| IEEE 802.3ab | |
| IEEE 802.3an | |
| IEEE 802.3az | |
| IEEE 802.3bz | |
| Device Interface | 5 x 10G ports (100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps) |
| LED indicators | |
| Throughput & Distance | Cat5e Cabling: 1Gbps/2.5Gbps @ 100m (328 ft.) |
| Cat6 Cabling: 10Gbps @ 50m (164 ft.)* | |
| Cat6a Cabling: 10Gbps @ 100m (328 ft.)* | |
| Data Transfer Rate | Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) |
| Gigabit Ethernet: 2000Mbps (full duplex) | |
| 2.5 Gigabit Ethernet: 5Gbps (full duplex) | |
| 5 Gigabit Ethernet: 10Gbps (full duplex) | |
| 10 Gigabit Ethernet: 20Gbps (full duplex) | |
| Performance | Switch fabric: 60Gbps |
| RAM buffer: 2MB | |
| MAC address table: 16K entries | |
| Jumbo frames: 9KB | |
| Forwarding mode: store and forward | |
| Forwarding rate: 44.64Mpps (64-byte packet size) | |
| Power | Input: 100 – 240V AC, 50/60 Hz |
| Output: 12V, 1A | |
| Max. Consumption: 11.9W | |
| MTBF | 379,884 hours |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 95% non-condensing |
| Dimensions | 180 x 145 x 33mm (7 x 5.7 x 1.3 in.) |
| Weight | 2.33 kg (5.12 lbs.) |
| Certifications | CE |
| FCC | |
| IC | |
