Description
- 24 x Gigabit PoE+ ports (up to 30W per port)
- 2 x Gigabit SFP Slots
- 380W PoE power budget
- 52Gbps switching capacity
- Internal power supply
- Sturdy 1U 19” rack-mountable metal housing
| Specifications | |
| Standards | IEEE 802.3 |
| IEEE 802.3u | |
| IEEE 802.3x | |
| IEEE 802.3ab | |
| IEEE 802.3af | |
| IEEE 802.3at | |
| Device Interface | 24 x Gigabit PoE+ ports |
| 2 x Gigabit SFP slots | |
| LED indicators | |
| Data Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) |
| Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) | |
| Gigabit: 2000Mbps (full duplex) | |
| SFP: 2000Mbps (full duplex) | |
| Performance | Data RAM Buffer: 512KB |
| Switch Fabric: 52Gbps | |
| MAC Address Table: 8K entries | |
| Forwarding rate: 35.7Mpps (64-byte packet size) | |
| Jumbo Frame: 10KB | |
| Power | Input: 100 – 240V AC, 50/60Hz, internal power supply |
| Max. consumption: 40W (no PD) | |
| PoE | PoE budget: 380W |
| PoE Mode A: Pins 1, 2, 3, and 6 for power | |
| Over current protection | |
| Short circuit protection | |
| Fan/Acoustics | Quantity: 2 |
| Max. noise Level: 30dB | |
| MTBF | 480,878 hours |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 435 x 195 x 44mm (17.12 x 8.3 x 7.67 in.) |
| Weight | 3.04kg (6.7 lbs.) |
| Certifications | CE |
| FCC | |
| ETL | |
