Description
The Ubiquiti NanoBeam AC Gen2 is an airMAX CPE (Customer Premises Equipment) is ideal for CPE deployments requiring maximum performance from the smallest possible footprint.
Key Features
Frequency 5 Ghz
Throughput 450+
Mbps Range 15+ km
Improved Wide Bandwidth Antenna
Dedicated Wi-Fi Radio for Management airMAX ac Processor for Superior Performance
| Specifications | |
| Dimensions | 189 x 189 x 125 mm (7.44 x 7.44 x 4.92″) |
| Weight | 0.530 kg (1.17 lb) |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Max. Power Consumption | 8.5W |
| Gain | 19 dBi |
| Networking Interface | (2) 10/100/1000 Ethernet Ports Wi-Fi for Management |
| Processor Specs | Atheros MIPS 74Kc, 720 MHz |
| Memory | 128 MB DDR2, 8 MB Flash |
| LEDs | Power, Ethernet, (4) Signal Strength |
| Signal Strength LEDs | Software-Adjustable to Correspond to Custom RSSI Levels |
| Max. VSWR | 1.5:1 |
| Channel Sizes | PtP Mode: 10/20/30/40/50/80 MHz PtMP Mode: 10/20/30/40 MHz |
| Polarization | Dual Linear |
| Enclosure | Outdoor UV Stabilized Plastic |
| Mounting | Pole-Mount (Kit Included), Wall-Mount |
| Wind Loading | 45.4 N @ 200 km/h (10.2 lbf @ 125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Operating Temperature | -40 to 80° C (-40 to 176° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| RoHS Compliance | Yes |
| Salt Fog Test | IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5 |
| Vibration Test | IEC 68-2-6 |
| Temperature Shock Test | IEC 68-2-14 |
| UV Test | IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4 |
| Wind-Driven Rain Test | ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5 |
