The Ubiquiti UniFi AC Pro
The UAP-AC-PRO UniFi Access Point Enterprise Wi-Fi System is a scalable enterprise access point solution designed to be easily deployed and managed. It supports the 802.11ac Wi-Fi standard with speeds of up to 1300 Mb/s in the 5 GHz radio band, and up to 450 Mb/s in the 2.4 GHz radio band. The Wi-Fi system offers simultaneous dual band operation with 3 x 3 MIMO technology for each band and convenient 802.3af PoE/802.3at PoE+ compatibility. It has a range of up to 400′ and two Gigabit Ethernet ports. This UniFi Access Point (AP) has a sleek design and can be easily mounted to a ceiling tile or wall, using the included mounting hardware. Sporting a weatherproof design, it can be deployed both indoors and outdoors, in wireless networks requiring maximum performance.
Specifications | |
Dimensions | 196.7 x 196.7 x 35 mm (7.74 x 7.74 x 1.38″) |
Weight | 350 g (12.4 oz) |
With Mounting Kits | 450 g (15.9 oz) |
Networking Interface | (2) 10/100/1000 Ethernet Ports |
Port | (1) USB 2.0 Port |
Buttons | Reset |
Power Method | Passive Power over Ethernet (48V), 802.3af/802.3at Supported (Supported Voltage Range: 44 to 57VDC) |
Power Supply | UniFi Switch (PoE) |
Power Save | Supported |
Maximum Power Consumption | 9W |
Maximum TX Power 2.4 GHz 5 GHz |
22 dBm 22 dBm |
Antennas | (3) Dual-Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 3 dBi |
Wi-Fi Standards | 802.11 a/b/g/n/r/k/v/ac |
Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
PSSID | Up to 8 per Radio |
Mounting | Wall/Ceiling (Kits Included) |
Operating Temperature | -10 to 70° C (14 to 158° F) |
Operating Humidity | 5 to 95% Noncondensing |
Certifications | CE, FCC, IC |
