Features
- 1 x Gigabit PoE+ input port
- 2 x Gigabit PoE output ports
- 2 x Gigabit ports
- 18W PoE power budget
- Easy to use web-based management interface
- Supports static link aggregation, VLAN, QoS, STP, RSTP and IGMP Snooping
- Voice VLAN for VoIP applications
- Bandwidth control per port
- 10Gbps switching capacity
- 802.1p / DSCP / Queue Scheduling (SP/WRR) QoS support
- Compact fanless design
- Wall mountable metal housing
| Specifications | |
| Standards | IEEE 802.1d |
| IEEE 802.1w | |
| IEEE 802.1p | |
| IEEE 802.1Q | |
| IEEE 802.3 | |
| IEEE 802.3u | |
| IEEE 802.3x | |
| IEEE 802.3ab | |
| IEEE 802.3af | |
| IEEE 802.3at | |
| IEEE 802.3az | |
| Device Interface | 1 x Gigabit PoE+ PD port |
| 2 x Gigabit PoE PSE ports | |
| 2 x Gigabit Ports | |
| LED indicators | |
| Reset button | |
| Data Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) |
| Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) | |
| Gigabit Ethernet: 2000Mbps (full duplex) | |
| Performance | Switch fabric: 10Gbps |
| RAM buffer: 48KB | |
| MAC Address Table: 2K entries | |
| Jumbo Frames: 9KB | |
| Forwarding rate: 7.44Mpps (64-byte packet size) | |
| Management | HTTP Web based GUI |
| SNMP v1, v2c | |
| Cable diagnostic test | |
| Backup/Restore Configuration | |
| Upload Firmware | |
| Spanning Tree | IEEE 802.1d STP (spanning tree protocol) |
| IEEE 802.1w RSTP (rapid spanning tree protocol) | |
| Link Aggregation | Static link aggregation (up to 2 groups) |
| Quality of Service (QoS) | Port-based QoS |
| 802.1p Class of Service (CoS) | |
| Bandwidth Control/Rate Limiting per port (Min. Limit: 8Kbps) | |
| Queue Scheduling: Strict Priority (SP), Weighted Fair Queueing (WFQ) | |
| VLAN | Port-based VLAN |
| 802.1Q Tagged VLAN | |
| Up to 32 VLAN groups, ID Range 1-4094 | |
| Private VLAN | |
| Asymmetric VLAN | |
| Voice VLAN (5 user defined OUIs) | |
| Multicast | IGMP Snooping v1/2/3 |
| Block unknown multicast source | |
| Up to 32 multicast groups | |
| Port Mirror | One to one |
| Many to one | |
| Storm Control | Broadcast (Min. Limit: 8Kbps) |
| Multicast (Min. Limit: 8Kbps) | |
| Loopback Detection | |
| Special Features | PoE Powered |
| Enable/disable 802.3az Power Saving | |
| Wall mountable | |
| Power | IEEE 802.3at (30W) or IEEE 802.3af (15.4W) PoE input only (no external power supply) |
| IEEE 802.3at Type 2 PoE PD Class 4 | |
| IEEE 802.3af Type 1 PoE PD Class 0 | |
| Max. Consumption 2.4W (without PoE load) | |
| Max. Consumption 24W (with max PoE load) | |
| PoE | 18W PoE Budget with IEEE 802.3at (30W) input power |
| 8W PoE Budget with IEEE 802.3af (15.4W) input power | |
| PoE Mode A: Pins 1,2 for power and pins 3,6 for power | |
| PD auto classification | |
| Over current/short circuit protection | |
| Fan / Acoustics | Fanless design |
| MTBF | 2,357,475 hours |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 150 x 97 x 28.6mm (5.9 x 3.81 x 1.12 in.) |
| Weight | 370g (13.05 oz.) |
| Certifications | CE |
| FCC | |
